AFAM chain kit for KTM SX-F 450 20-22 520 MX6GG chain kit

AFAM Chain Kit for KTM SX-F 450 20-22 520 MX6GG Chain Kit

Chain kit or chain set for the assigned model as per the article name. The chain kit consists of high-quality components. The chain is supplied open with a corresponding connecting link.

Unless otherwise stated: Not an original part - manufacturer names are only used to indicate compatibility!

Components of the chain kit KTM SX-F 450 4T 2020-2022

• Front sprocket: AFAM front sprocket #520 SC 13 teeth - a73301.13sc
• Chain: AFAM chain 520 MX6-GG 118 with clip link - a520mx6.gg.118
• Rear sprocket: Esjot rear sprocket 71304-49 STEEL #520 49 teeth - a71304.49
• Gear ratio front sprocket-chain-rear sprocket: 13-118-49

AFAM 520 MX6-GG MX Racing GP

Pure motocross chain
Without O-rings
Color: Gold/Gold
Application by displacement: up to 500 cc / motocross only

Technical data:
Pitch: 520
Pin length: 16.8 mm
Roller Ø: 10.16 mm
Plate thickness: inner: 2.0 mm
Plate thickness: outer: 2.0 mm
Tensile strength: 37.40 kN
Weight per 100 links: 1.64 kg

Unless otherwise stated: The product offered is an accessory/spare part from a third-party manufacturer and was not produced on behalf of or with the approval of the motorcycle manufacturer. The mention of the brand name serves solely to determine compatibility.

DC-AFAM NV, Venecoweg 22A , 9810 Nazareth BE, service@afam.com

Technical data

Brand	AFAM
Part number	KKF-63668

Suitable for

KTM 251 - 500 cc SX-F 450 4T 2020
KTM 251 - 500 cc SX-F 450 4T 2021
KTM 251 - 500 cc SX-F 450 4T 2022
