AFAM chain kit for Suzuki DL 650 V-Strom ABS 12-16 525 XHR3G chain kit

AFAM Chain Kit for Suzuki DL 650 V-Strom ABS 12-16 525 XHR3G Chain Kit

Chain kit or chain set for the assigned model as per the article name. The chain kit consists of high-quality components. The chain is supplied open with a corresponding connecting link.

Unless otherwise stated: Not an original part - manufacturer names are used only to indicate compatibility!

Components of the chain kit Suzuki DL 650 V-Strom ABS WVC7 2012-2016

• Front sprocket: AFAM front sprocket #525 15 teeth - a28401.15
• Chain: AFAM chain 525 XHR3-G Xs-ring 118 with rivet link - a525xhr3.g.118
• Rear sprocket: AFAM rear sprocket STEEL #525 47 teeth - a14604.47
• Gear ratio front sprocket-chain-rear sprocket: 15-118-47

AFAM 525 XHR3-G

Hyper-reinforced chain with low-friction properties. The "all-rounder"!
Xs-ring chain
Color: Gold
Application by displacement: up to 1000 cc / road and sport

Technical data:
Pitch: 525
Pin length: 23.10 mm
Roller Ø: 10.20 mm
Plate thickness: inner: 2.4 mm
Plate thickness: outer: 2.6 mm
Tensile strength: 48.90 kN
Weight per 100 links: 2.06 kg

Unless otherwise stated: The offered product is an accessory/spare part from a third-party manufacturer and was not produced on behalf of or with the approval of the motorcycle manufacturer. The brand name is used exclusively to determine compatibility.

DC-AFAM NV, Venecoweg 22A , 9810 Nazareth BE, service@afam.com

Technical data

Brand	AFAM
Item number	KKF-52174

Suitable for

Suzuki 501 - 750 cc DL 650 V-Strom ABS WVC7 2012
Suzuki 501 - 750 cc DL 650 V-Strom ABS WVC7 2013
Suzuki 501 - 750 cc DL 650 V-Strom ABS WVC7 2014
Suzuki 501 - 750 cc DL 650 V-Strom ABS WVC7 2015
Suzuki 501 - 750 cc DL 650 V-Strom ABS WVC7 2016
