AFAM chain kit for Suzuki GS 450 S 1988 530 XHR2G chain kit

AFAM chain kit for Suzuki GS 450 S 1988 530 XHR2G chain kit

Chain kit or chain set for the assigned model according to the article name. The chain kit consists of high-quality components. The chain is supplied open with a matching master link.

Unless otherwise stated: Not an original part - manufacturer names are only used to indicate compatibility!

Components of the chain kit Suzuki GS 450 S GL51F 1988-1988

• Sprocket: AFAM sprocket #530 16 teeth - a28400.16
• Chain: AFAM chain 530 XHR2-G Xs-ring 110 with rivet master link - a530xhr2.g.110
• Rear sprocket: AFAM rear sprocket STEEL #530 45 teeth - a14400.45
• Gear ratio sprocket-chain-rear sprocket: 16-110-45

AFAM 530 XHR2-G

Hyper-reinforced chain with low-friction properties. The "all-rounder"!
Xs-ring chain
Color: Gold
Application by displacement: up to 1400 cc / street and sport

Technical data:
Pitch: 530
Pin length: 24.70 mm
Roller Ø: 10.20 mm
Plate thickness: inner: 2.4 mm
Plate thickness: outer: 2.6 mm
Tensile strength: 48.90 kN
Weight per 100 links: 2.16 kg

Unless otherwise stated: The offered goods are accessory/spare parts from a third-party manufacturer and were not produced on behalf of or with the approval of the motorcycle manufacturer. The mention of the brand is solely for the purpose of determining compatibility.

DC-AFAM NV, Venecoweg 22A , 9810 Nazareth BE, service@afam.com

Technical data

Brand	AFAM
Item number	KKF-41836

Suitable for

Suzuki 251 - 500 cc GS 450 S GL51F 1988
