AFAM chain kit for Triumph Tiger 800 XRX Low ABS 18-20 525 XSR2G chain kit

AFAM Chain kit for Triumph Tiger 800 XRX Low ABS 18-20 525 XSR2G Chain kit

Chain kit or chain set for the assigned model as per the article name. The chain kit consists of high-quality components. The chain is supplied open with a matching master link.

Unless otherwise stated: Not an original part - manufacturer names are used for compatibility purposes only!

Components of the chain kit Triumph Tiger 800 XRX Low ABS C3 2018-2020

• Sprocket: AFAM sprocket #525 16 teeth - a28401.16
• Chain: AFAM chain 525 XSR2-G Xs-ring 124 w. rivet link - a525xsr2.g.124
• Rear sprocket: AFAM rear sprocket STEEL #525 50 teeth - a86605.50
• Gear ratio sprocket-chain-rear sprocket: 16-124-50

AFAM 525 XSR2-G

Super reinforced chain with low-friction properties
Xs-ring chain
Color: Gold
Application by displacement: up to 1000 cc / street and sport

Technical data:
Pitch: 525
Pin length: 22.75 mm
Roller Ø: 10.20 mm
Plate thickness: inner: 2.2 mm
Plate thickness: outer: 2.4 mm
Tensile strength: 41.80 kN
Weight per 100 links: 1.90 kg

Unless otherwise stated: The offered goods are an accessory/spare part from a third-party manufacturer, which was not manufactured on behalf of or with the approval of the motorcycle manufacturer. The mention of the brand is solely for the purpose of determining compatibility.

DC-AFAM NV, Venecoweg 22A , 9810 Nazareth BE, service@afam.com

Technical data

Brand	AFAM
Article number	KKF-51241

Fits

Triumph 751 - 1000 cc Tiger 800 XRX Low ABS C3 2018
Triumph 751 - 1000 cc Tiger 800 XRX Low ABS C3 2019
Triumph 751 - 1000 cc Tiger 800 XRX Low ABS C3 2020
