AFAM chain kit for Triumph Tiger 955 i 01-04 530 XSR2G chain kit

AFAM chain kit for Triumph Tiger 955 i 01-04 530 XSR2G chain kit

Chain kit or chain set for the assigned model as per the article name. The chain kit consists of high-quality components. The chain is supplied open with a matching master link.

Unless otherwise stated: Not an original part - manufacturer names are used only to indicate compatibility!

Components of the chain kit Triumph Tiger 955 i 709EN 2001-2004

• Sprocket: AFAM sprocket #530 TRI 900-1200 18 teeth - a88800.18
• Chain: AFAM chain 530 XSR2-G Xs-ring 114 with rivet link - a530xsr2.g.114
• Rear sprocket: AFAM rear sprocket STEEL #530 46 teeth - a86600.46
• Gear ratio sprocket-chain-rear sprocket: 18-114-46

AFAM 530 XSR2-G

Super reinforced chain with smooth-running properties
Xs-ring chain
Color: Gold
Application by displacement: up to 1100 cc / road and sport

Technical data:
Pitch: 530
Pin length: 24.40 mm
Roller Ø: 10.20 mm
Plate thickness: inner: 2.2 mm
Plate thickness: outer: 2.4 mm
Tensile strength: 41.80 kN
Weight per 100 links: 2.05 kg

Unless otherwise stated: The product offered is an accessory/spare part from a third-party manufacturer, which was not produced on behalf of or with the approval of the motorcycle manufacturer. The mention of the brand is solely for the purpose of determining compatibility.

DC-AFAM NV, Venecoweg 22A , 9810 Nazareth BE, service@afam.com

Technical data

Brand	AFAM
Item number	KKF-52981

Suitable for

Triumph 751 - 1000 cc Tiger 955 i 709EN 2001
Triumph 751 - 1000 cc Tiger 955 i 709EN 2002
Triumph 751 - 1000 cc Tiger 955 i 709EN 2003
Triumph 751 - 1000 cc Tiger 955 i 709EN 2004
