AFAM chain kit for Triumph Trident 660 ABS 21-24 520 XSRG chain kit

AFAM chain kit for Triumph Trident 660 ABS 21-24 520 XSRG chain kit

Chain kit or chain set for the assigned model according to the item name. The chain kit consists of high-quality components. The chain is supplied open with a corresponding master link.

Unless otherwise stated: Not an original part - manufacturer names are only used to indicate compatibility!

Components of the chain kit Triumph Trident 660 ABS L101 2021-2024

• Front sprocket: AFAM sprocket #520 16 teeth - a27500.16
• Chain: AFAM chain 520 XSR-G Xs-ring 120 with rivet link - a520xsr.g.120
• Rear sprocket: AFAM rear sprocket STEEL #520 51 teeth - a86606.51
• Gear ratio sprocket-chain-rear sprocket: 16-120-51

AFAM 520 XSR-G

Super reinforced chain with low-friction properties
Xs-ring chain
Color: Gold
Application by displacement: up to 800 cc / road, sport and off-road

Technical specifications:
Pitch: 520
Pin length: 20.10 mm
Roller Ø: 10.20 mm
Plate thickness: inner: 2.0 mm
Plate thickness: outer: 2.0 mm
Tensile strength: 36.30 kN
Weight per 100 links: 1.58 kg

Unless otherwise stated: The product offered is an accessory/spare part from a third-party manufacturer, which was not produced on behalf of or with the approval of the motorcycle manufacturer. The mention of the brand name is solely for the purpose of determining compatibility.

DC-AFAM NV, Venecoweg 22A , 9810 Nazareth BE, service@afam.com

Technical specifications

Brand	AFAM
Item number	KKF-77931

Suitable for

Triumph 501 - 750 cc Trident 660 ABS L101 2021
Triumph 501 - 750 cc Trident 660 ABS L101 2022
Triumph 501 - 750 cc Trident 660 ABS L101 2023
Triumph 501 - 750 cc Trident 660 ABS L101 2024
