DID chain kit for MV Agusta F3 800 RC ABS 19-20 525 ZVM-X2 chain kit

DID chain kit for MV Agusta F3 800 RC ABS 19-20 525 ZVM-X2 chain kit

Chain kit or chain set for the assigned model as per the article name. The chain kit consists of high-quality components. The chain is supplied open with a matching chain link.

Unless otherwise stated: Not an original part - Mention of manufacturer is for compatibility purposes only!

Components of the MV Agusta F3 800 RC ABS 2019-2020 chain kit

• Sprocket: AFAM sprocket #525 17 teeth - a94605.17
• Chain: DID chain 525 ZVM-X2 G&G 116 with rivet link - d525zvmx2.gg.116
• Rear sprocket: AFAM rear sprocket STEEL #525 43 teeth - a92836.43
• Gear ratio sprocket-chain-rear sprocket: 17-116-43

DID 525 ZVM-X2

Extra reinforced chain, versatile range of use
X-ring chain
Color: Gold/Gold
Application by displacement: up to 1300 cc

Technical specifications:
Pitch: 525
Pin length: 23.2 mm
Roller Ø: 10.32 mm
Inner plate thickness: 2.4 mm
Outer plate thickness: 2.6 mm
Wear resistance index: 4000
Tensile strength: 47.20 kN
Weight per 100 links: 2.11 kg

Unless otherwise stated: The offered product is an accessory/spare part from a third-party manufacturer, which was not manufactured on behalf of or with the approval of the motorcycle manufacturer. The mention of the brand is solely for the purpose of determining compatibility.

DID EUROPE S.R.L., Via del Fonditore 16 , 40138 Bologna IT, info@dideu.it

Technical specifications

Brand	DID
Part number	KKF-63929

Suitable for

MV Agusta 751 - 1000 cc F3 800 RC ABS 2019
MV Agusta 751 - 1000 cc F3 800 RC ABS 2020
