DID chain kit for Suzuki GSR 600 ABS 06-10 525 ZVM-X2 chain kit

DID Chain Kit for Suzuki GSR 600 ABS 06-10 525 ZVM-X2 Chain Kit

Chain kit or chain set for the assigned model as per item name. The chain kit consists of high-quality components. The chain is supplied open with an appropriate connecting link.

Unless otherwise stated: Not an original part - manufacturer names are mentioned for compatibility purposes only!

Components of the chain kit Suzuki GSR 600 ABS WVB9 2006-2010

• Sprocket: AFAM sprocket #525 16 teeth - a28401.16
• Chain: DID chain 525 ZVM-X2 G&G 114 w. rivet link - d525zvmx2.gg.114
• Rear sprocket: AFAM rear sprocket STEEL #525 48 teeth - a14604.48
• Gear ratio sprocket-chain-rear sprocket: 16-114-48

DID 525 ZVM-X2

Extra reinforced chain, versatile range of use
X-ring chain
Color: Gold/Gold
Application by engine displacement: up to 1300 cc

Technical specifications:
Pitch: 525
Pin length: 23.2 mm
Roller Ø: 10.32 mm
Inner plate thickness: 2.4 mm
Outer plate thickness: 2.6 mm
Wear resistance index: 4000
Tensile strength: 47.20 kN
Weight per 100 links: 2.11 kg

Unless otherwise stated: The product offered is a third-party accessory/spare part, not manufactured on behalf of or with the approval of the motorcycle manufacturer. The brand name is used solely for the purpose of identifying compatibility.

DID EUROPE S.R.L., Via del Fonditore 16 , 40138 Bologna IT, info@dideu.it

Technical specifications

Brand	DID
Item number	KKF-64304

Suitable for

Suzuki 501 - 750 cc GSR 600 ABS WVB9 2006
Suzuki 501 - 750 cc GSR 600 ABS WVB9 2007
Suzuki 501 - 750 cc GSR 600 ABS WVB9 2008
Suzuki 501 - 750 cc GSR 600 ABS WVB9 2009
Suzuki 501 - 750 cc GSR 600 ABS WVB9 2010
